Chicago Pneumatic MR84-420-K-ATEX, Reversible Vane Air Motor, 630 W Power, 420 Rpm Free Speed – 2051479304
Original price
€2,580.95
-
Original price
€2,580.95
Original price
€2,580.95
€2,580.95
-
€2,580.95
Current price
€2,580.95
- Product Description
- Technical Specification
- Warranty Details
-
Product Number: 2051479304
The standard pneumatic vane motors MR84-420-K-ATEX is compact in design, light in weight, have Keyed shaft shaft spindle It is suitable for building using handheld machines or any industrial equipment. This reversible air motor delivers a maximum power of 630 W (0.83 hp), with a maximum torque of 53 Nm (39 ft.lbs) and 420 rpm free speed and is ATEX certified Ex II 2 G Ex h IIC T6 Gb for gas and Ex II 2 D Ex h IIIC T85C Db for dustCountry of origin is HU.Customs tariff is 84123900
-
- Air consumption at load: 14 l/s
- Air flow max power: 14 l/s
- Air inlet thread size (in): 3/8
- Air inlet thread type: BSP
- Max dynamic air working pressure: 6.3 bar
- Safety: Index of protection (IP code)
- Max free speed range: 420 rpm
- Minimum starting torque: 35 Nm
- Stall torque: 53 Nm
- Torque at max power: 26 Nm
- Max output power: 0.6 kW
- Back Head Coaxial: No
- Front nut threaded: No
- Main Material type: Steel
- Motor Lubrication free: No
- Rotation drive: Reversible
- Shaft loading code: e
- Spindle type: Keyed shaft
- Starting system: None
- Output Spindle size: 10 mm
- Weight: 1.3 kg
-
New Grade - 24 Months Warranty from purchase is available on this product.
