Chicago Pneumatic CP6641, 1" Air Impact Wrench with ATC Pack
- Product Description
- Technical Specification
- Warranty Details
-
Product Number: 6151800140
The Chicago Pneumatic CP6641 with ATC Pack delivers the kind of brute fastening power that serious industrial operations demand, combining precision torque control with exceptional raw output in a robust 1-inch drive package. Engineered for heavy-duty assembly lines, maintenance workshops, and structural steel applications, this cp impact wrench produces an impressive 4100 Nm of maximum torque in both forward and reverse, ensuring relentless performance whether driving or removing the most stubborn fasteners. The minimum forward torque of 1000 Nm provides meaningful operational range, giving technicians reliable control across a wide spectrum of fastening tasks without sacrificing productivity. The ATC Pack configuration bundles ten reaction arms alongside the CP6641, making this air impact wrench an immediately deployable solution for high-volume torque applications where consistent, repeatable results are non-negotiable. The Non-Shut-Off torque control system keeps the tool running continuously through the fastening cycle, supporting streamlined throughput on demanding production floors. Built on Chicago Pneumatic's trusted engineering heritage, this chicago pneumatic impact wrench reflects decades of innovation in pneumatic tooling, delivering the durability and performance that plant engineers and assembly specialists rely on shift after shift. Whether tackling large-diameter bolted flange connections in oil and gas infrastructure, securing heavy structural joints in construction, or managing high-torque assembly in agricultural and mining equipment manufacturing, the CP6641 ATC Pack proves itself as a dependable, productivity-driving tool investment for any operation where precision and power must coexist.Product Feature: Compact tool for tight high torque application Industrial FRL ATC pack for high accuracy Vane type impact wrench air motor for high performance Lightweight, swivelling handle and one-finger reverse mode for high operator comfort About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.
-
- Max torque in forward: 4100 Nm
- Max torque reverse: 4100 Nm
- Min torque in forward: 1000 Nm
- Torque Control System: Non shut-off-stall
- Accuracy (%): ±5 %
- Adjustment: Torque Chart
- Handle type: Pistol
- Joint Type: Hard & Soft
- Main Material type: Composite
- Output drive size: 1 in
- Output drive type: Sq
- Output retainer type: Hole
- Reaction bar type: S-type
- Reversible: Yes
- Spline type: 70
- Starting system: Trigger
- Suspension option: Optional
- Height (H): 228 mm
- Length (L): 361 mm
- Width (W): 100 mm
- Side to Center: 40 mm
- Weight: 8.8 kg
- Weight without reaction arm: 8.8 kg
- Weight with reaction arm: 10.8 kg
- Sound Power: 101 dB(A)
- Sound Pressure: 90 dB(A)
- Vibration: 2.1 m/s²
- Vibration (m/s²): <2.5
- Free Speed: 10 rpm
- Air consumption at free speed: 31 l/s
- Air inlet thread size: 3/8 in
- Air inlet thread type: NPT
- Max dynamic air working pressure: 6.3 bar
- Min hose diam (5 m hose length): 16 mm
-
New Grade - 24 Months Warranty from purchase is available on this product.
