Chicago Pneumatic CP6626, 1" Air Impact Wrench with ATC Pack
- Product Description
- Technical Specification
- Warranty Details
-
Product Number: 6151800130
The Chicago Pneumatic CP6626 with ATC Pack delivers the raw, reliable power that heavy-duty assembly and maintenance professionals demand, pairing an impressive 2,600 Nm of maximum forward and reverse torque with the precision of an integrated Automatic Torque Control system. Designed for demanding industrial environments where accuracy and consistency are non-negotiable, this 1'' drive air impact wrench handles even the most stubborn fasteners with authority, offering a minimum torque threshold of 700 Nm that gives operators meaningful control across a broad working range. As a cp impact wrench built to Chicago Pneumatic's exacting standards, the CP6626 ATC Pack is engineered for applications where repeatable torque output matters as much as sheer muscle. The non-shut-off torque control system ensures continuous drive force, making it particularly well-suited to high-cycle production lines and heavy vehicle maintenance where stopping mid-task is not an option. The matched ATC Pack configuration means operators receive everything needed to integrate this tool seamlessly into existing pneumatic setups, reducing downtime and simplifying procurement. As a best-in-class chicago pneumatic impact wrench, this unit excels in rail, mining, oil and gas, and commercial vehicle workshops where 1'' drive capability and consistent 2,600 Nm performance separate productive operations from costly bottlenecks. Whether tackling wheel assemblies, structural bolting, or large-diameter pipe flanges, the CP6626 ATC Pack is the professional's choice for uncompromising torque delivery.Product Feature: Compact tool for tight high torque application Industrial FRL ATC pack for high accuracy Vane type impact wrench air motor for high performance Lightweight, swivelling handle and one-finger reverse mode for high operator comfort About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.
-
- Max torque in forward: 2600 Nm
- Max torque reverse: 2600 Nm
- Min torque in forward: 700 Nm
- Torque Control System: Non shut-off-stall
- Accuracy (%): ±5 %
- Adjustment: Torque Chart
- Handle type: Pistol
- Joint Type: Hard & Soft
- Main Material type: Composite
- Output drive size (in): 1
- Output drive type: Sq
- Output retainer type: Hole
- Reaction bar type: S-type
- Reversible: Yes
- Spline type: 47
- Starting system: Trigger
- Suspension option: Optional
- Free Speed: 10 rpm
- Air consumption at free speed: 23 l/s
- Height (H): 212 mm
- Length (L): 300 mm
- Width (W): 72 mm
- Side to Center: 34 mm
- Weight: 5.1 kg
- Weight without reaction arm: 5.1 kg
- Weight with reaction arm: 6.5 kg
- Sound Power: 101 dB(A)
- Sound Pressure: 90 dB(A)
- Vibration (m/s²): <2.5
- Vibration: 2.8 m/s²
- Air inlet thread size (in): 3/8
- Air inlet thread type: NPT
- Max dynamic air working pressure: 6.3 bar
- Min hose diam (5 m hose length): 16 mm
-
New Grade - 24 Months Warranty from purchase is available on this product.
