Chicago Pneumatic CP6613, 3/4" Air Impact Wrench
- Product Description
- Technical Specification
- Warranty Details
-
Product Number: 6151800090
The Chicago Pneumatic CP6613 3/4'' stall torque nutrunner delivers the kind of controlled, repeatable fastening performance that heavy-duty assembly operations demand, making it a standout choice among professional-grade air impact wrenches built for precision work. Engineered to handle the most demanding bolting applications, this chicago pneumatic impact wrench produces a maximum forward and reverse torque of 1300 Nm, while its minimum forward torque of 320 Nm provides meaningful range across a variety of fastening tasks. Operating at a controlled 20 RPM, the CP6613 prioritises consistent torque delivery over raw speed, ensuring fasteners are driven with accuracy rather than aggression. The stall torque design means the tool reaches its peak output and holds it, giving operators a reliable feel for when the fastener has reached the correct tension. With its non shut-off torque control system, the CP6613 is well suited to applications where the operator manages final torque through technique and tool selection rather than automatic cutoff mechanisms. The robust 3/4'' drive is purpose-built for large fasteners typically found in heavy equipment, structural steelwork, and commercial vehicle assembly. As a cp impact wrench renowned for durability and consistent output, the CP6613 is the preferred tool for automotive production lines, truck and bus manufacturing facilities, and industrial maintenance teams where high-torque reliability throughout long shifts is absolutely non-negotiable.Product Feature: Compact tool for tight high torque application Industrial FRL ATC pack for high accuracy Vane type impact wrench air motor for high performance Lightweight, swivelling handle and one-finger reverse mode for high operator comfort About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.
-
- Max torque in forward: 1300 Nm
- Max torque reverse: 1300 Nm
- Min torque in forward: 320 Nm
- Torque Control System: Non shut-off-stall
- Accuracy (%): ±5 %
- Adjustment: Torque Chart
- Handle type: Pistol
- Joint Type: Hard & Soft
- Main Material type: Composite
- Output drive size (in): 3/4
- Output drive type: Sq
- Output retainer type: Hole
- Reaction bar type: S-type
- Reversible: Yes
- Spline type: 40
- Starting system: Trigger
- Suspension option: Optional
- Free Speed: 20 rpm
- Air consumption at free speed: 23 l/s
- Height (H): 212 mm
- Length (L): 254 mm
- Width (W): 72 mm
- Side to Center: 32 mm
- Weight: 3.7 kg
- Weight without reaction arm: 3.7 kg
- Weight with reaction arm: 4.4 kg
- Sound Power: 101 dB(A)
- Sound Pressure: 90 dB(A)
- Vibration (m/s²): <2.5
- Vibration: 2.5 m/s²
- Air inlet thread size (in): 3/8
- Air inlet thread type: NPT
- Max dynamic air working pressure: 6.3 bar
- Min hose diam (5 m hose length): 16 mm
-
New Grade - 24 Months Warranty from purchase is available on this product.
