GF12052YO Sonnenschein Gel Cyclic Battery GF-Y, 12V 60Ah, 1 Year Warranty

Original price £221.72 - Original price £221.72
Original price
£221.72
£221.72 - £221.72
Current price £221.72
  • Product Description
  • Technical Specification
  • Warranty Details
  • Product Number: GF12052YO

    Cyclic applications demand a battery that can withstand repeated deep discharge and recharge cycles without capacity degradation - a challenge that standard lead-acid designs struggle to meet. The Sonnenschein GF12052YO is a 12V 60Ah gel cyclic battery from the GF-Y (dryfit? A500 Cyclic) range, engineered specifically for demanding leisure and mobility applications including electric boats, golf carts, powered wheelchairs, and mobility scooters. Built on Sonnenschein's proven dryfit? technology, the GF12052YO uses VRLA (valve regulated lead-acid) construction in which the electrolyte is permanently fixed within a gel matrix. This eliminates electrolyte stratification and acid spillage risk, and the sealed design renders the battery entirely maintenance-free throughout its service life - no topping up is required. The range is rated to 450 cycles under standard cyclic test conditions. The battery measures 261mm x- 170mm - 178mm (L x- W x- H) and weighs 19.8kg. It features a Type 1 terminal arrangement, Hold-Down B00, and Polarity 1 configuration. No direct cross-reference codes are confirmed for this SKU; compatibility should be verified against original equipment specifications prior to fitment. Start-stop suitability is not confirmed - refer to the product label. The GF12052YO is one of several capacities within the Sonnenschein GF-Y range. Related variants include GF12022YT, GF12025YG, GF12033Y1, GF12033YG1, GF12033YG2, GF12040Y, GF12044Y, and GF12051Y1, covering a range of capacities to suit differing cyclic energy requirements." This product is supplied with a 1-year manufacturer warranty. " . Range GF-Y (dryfit® A500 Cyclic) The GF-Y range is particularly suitable for the leisure market with applications including electric boats, golf carts, and scooters. Key Feature: VRLA (valve regulated battery technology), electrolyte is fixed in a gel Maintenance-free (no topping up) during the whole service life due to the Sonnenschein dryfit® technology 450 cycles according to IEC 60254-1 Very robust Backed by 1-year warranty for reliable use and dependable performance. Product Group: 5200, SONNENSCHEIN CYCLIC BATTERY GF-Y, Sonnenschein Gel Battery, purpose-built for dependable performance in the intended application. Engineered as a Gel Battery, delivering consistent, reliable operation in daily use. Manufactured by Sonnenschein, a trusted name known for dependable quality. Weighs 19.8, balancing power and manageability for easier installation and handling. . OEM-style fitment supports straightforward replacement and proper mounting. 12V system compatibility with standard vehicle electrical requirements. Compatibility: Suited for marine and RV applications, supporting engine cranking and house loads for regular use. Uses: Provides robust cranking power for marine/RV engines and onboard systems. Supports house loads and accessories with stable reserve capacity. Handles intermittent use and storage with dependable restarts. Designed for multi-€˜stop trips and auxiliary power needs afloat or on the road. About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.

    • Brand: Sonnenschein
    • Voltage: 12V
    • Capacity AH (C20): 60Ah
    • Cold Cranking Amps (EN):
    • L x- W x- H: 261mm x- 170mm x- 178mm
    • Warranty period: 1 Year
    • Weight (Kg): 19.8
    • Capacity AH (C5):
    • Capacity AH (C10):
    • Capacity AH (C100):
    • Marine Cranking Amps (MCA):
    • Watt-Hours (WH):
    • Length (mm): 261
    • Width (mm): 170
    • Height Inc. Terminal (mm): 178
    • Terminal Placement: 1
    • Terminal Type: 1
    • Hold Down: B00
    • Case Size:
    • ETN Number:
    • TTNR:
  • New Grade - 24 Months Warranty from purchase is available on this product.
Frequently Asked Questions

Q1- What voltage and capacity does the GF12052YO provide?
ANS- The Sonnenschein GF12052YO is a 12V battery with a rated capacity of 60Ah at the C20 rate, making it suitable for cyclic applications that require sustained energy delivery over repeated discharge cycles.

Q2- What technology does the GF12052YO use, and does it require maintenance?
ANS- The GF12052YO uses Sonnenschein dryfit® VRLA (valve regulated lead-acid) gel technology. The electrolyte is permanently fixed in a gel matrix, meaning the battery is entirely sealed and maintenance-free throughout its service life - no water or electrolyte topping up is required.

Q3- What are the physical dimensions and weight of the GF12052YO?
ANS- The battery measures 261mm in length, 170mm in width, and 178mm in height including the terminal. It weighs 19.8kg. These dimensions should be verified against the available battery tray or enclosure space before ordering.

Q4- What terminal type and polarity configuration does the GF12052YO have?
ANS- The GF12052YO features a Type 1 terminal arrangement with a Polarity 1 configuration and Hold-Down type B00. Confirm these specifications match your application's wiring and mounting requirements before fitting.

Q5- What applications is the GF12052YO designed for?
ANS- The Sonnenschein GF-Y (dryfit® A500 Cyclic) range is designed for leisure and mobility cyclic applications. Typical uses include electric boats, golf carts, powered wheelchairs, and mobility scooters - environments where deep, repeated discharge and recharge cycles are the normal operating pattern.

Q6- How many cycles is the GF12052YO rated for?
ANS- The GF-Y range is rated to 450 cycles under standard cyclic test conditions. Actual cycle life will depend on depth of discharge, charge regime, and ambient operating conditions.

Q7- Is the GF12052YO suitable for start-stop vehicle applications?
ANS- Start-stop suitability for the GF12052YO has not been confirmed. Please refer to the product label and consult your vehicle manufacturer's specifications before use in a start-stop application.

Q8- Are there cross-reference codes available for the GF12052YO?
ANS- No confirmed cross-reference codes are available for this SKU. Compatibility should be verified directly against your original equipment part number or the specifications of the battery being replaced.

Q9- What other capacities are available in the Sonnenschein GF-Y range?
ANS- The GF-Y range includes several variants to suit different cyclic energy requirements. Related SKUs available on MachineRefurb include GF12022YT, GF12025YG, GF12033Y1, GF12033YG1, GF12033YG2, GF12040Y, GF12044Y, and GF12051Y1.

Q10- What are the delivery and returns terms for the GF12052YO?
ANS- The GF12052YO is dispatched via standard parcel delivery. Standard delivery takes 1-3 working days within the UK mainland. A 30-day returns policy applies - please refer to the MachineRefurb returns policy for full terms and conditions.

Q11- What are the delivery times?
ANS- Estimated delivery times are as follows:
* Ireland: 1-3 business days
* UK Mainland: 1-3 business days
* Northern Ireland: 3-7 business days
* European Union: 3-7 business days
All orders are shipped with tracking. You will receive tracking details by email once dispatched.

Q12- What is the warranty period for this product?
ANS- This product is covered under a 1-year warranty from the date of purchase.
