Chicago Pneumatic MR84-5000-K-ATEX, ATEX Reversible Air Motor
- Product Description
- Technical Specification
- Warranty Details
-
Product Number: 2051479254
Delivering reliable rotational power in hazardous environments where safety cannot be compromised, the Chicago Pneumatic MR84-5000-K-ATEX reversible vane air motor offers 630 W of consistent performance engineered specifically for ATEX-certified applications. This robust pneumatic motor is built to operate safely in potentially explosive atmospheres, making it an indispensable solution for industries such as oil and gas, chemical processing, and mining where ignition risks demand the highest equipment standards. The MR84-5000-K-ATEX runs at a maximum speed of 5000 RPM, drawing an air consumption of 14 l/s at load with a matched air flow of 14 l/s at maximum power. Connecting effortlessly via a 3/8-inch BSP air inlet thread, this air motor integrates smoothly into existing compressed air systems without complex adaptation. The reversible vane design provides bidirectional operation, giving operators precise control over direction and versatility across demanding tasks. As a high-performance pneumatic motor within the Chicago Pneumatic lineup, this unit benefits from the brand's decades of engineering excellence and commitment to durability under continuous industrial use. Its compact yet powerful construction makes it well suited for driving specialised tooling in confined or sensitive environments where electric motors would pose unacceptable risks. The MR84-5000-K-ATEX is the ideal choice for engineers and maintenance professionals who require certified, dependable air-powered performance in classified hazardous zones without sacrificing power or operational flexibility.Product Feature: Low friction and lubrication-free design of vanes for ruggedness. Sustain stall torque loading indefinitely. Short and compact planetary gear system for versatile solutions Long lasting efficiency with low air consumption design Strong starting torque for mobility during operation About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.
-
- Air consumption at load: 14 l/s
- Air flow max power: 14 l/s
- Air inlet thread size (in): 3/8
- Air inlet thread type: BSP
- Max dynamic air working pressure: 6.3 bar
- Safety: Index of protection (IP code)
- Max free speed range: 5000 rpm
- Minimum starting torque: 3.1 Nm
- Stall torque: 4.6 Nm
- Torque at max power: 2.3 Nm
- Max output power: 0.6 kW
- Back Head Coaxial: No
- Front nut threaded: No
- Main Material type: Steel
- Motor Lubrication free: No
- Rotation drive: Reversible
- Shaft loading code: e
- Spindle type: Keyed shaft
- Starting system: None
- Output Spindle size: 10 mm
- Weight: 1.2 kg
-
New Grade - 24 Months Warranty from purchase is available on this product.
