Chicago Pneumatic MR84-3200-K-ATEX, ATEX Reversible Air Motor
- Product Description
- Technical Specification
- Warranty Details
-
Product Number: 2051479264
Delivering reliable, explosion-safe rotational power in the most demanding industrial environments, the Chicago Pneumatic MR84-3200-K-ATEX reversible vane air motor provides 630 W of consistent output where conventional electric motors simply cannot operate. Engineered for use in hazardous locations requiring ATEX certification, this robust pneumatic motor gives facilities in petrochemical, mining, and offshore industries the confidence to run continuous-duty applications without compromising safety compliance or operational efficiency. The MR84-3200-K-ATEX operates at a rated speed of 3200 RPM, drawing 14 l/s of air at load through a 3/8-inch BSP inlet connection, making integration into existing compressed air networks straightforward and efficient. The reversible vane design delivers smooth, controllable power in both directions, offering the kind of operational flexibility that fixed-direction air motors cannot match. As a purpose-built pneumatic motor, it eliminates spark risk in flammable atmospheres while maintaining the torque consistency and durability that Chicago Pneumatic tools are renowned for across global industrial markets. Compact yet powerful, this air motor suits applications including conveyor drives, agitators, winches, and material handling equipment where intrinsically safe power transmission is non-negotiable. Whether integrated into automated production lines or used in standalone machinery within Zone 1 or Zone 2 classified areas, the Chicago Pneumatic MR84-3200-K-ATEX is the trusted solution for engineers specifying dependable, hazardous-area-rated pneumatic drive systems.Product Feature: Low friction and lubrication-free design of vanes for ruggedness. Sustain stall torque loading indefinitely. Short and compact planetary gear system for versatile solutions Long lasting efficiency with low air consumption design Strong starting torque for mobility during operation About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.
-
- Air consumption at load: 14 l/s
- Air flow max power: 14 l/s
- Air inlet thread size (in): 3/8
- Air inlet thread type: BSP
- Max dynamic air working pressure: 6.3 bar
- Safety: Index of protection (IP code)
- Max free speed range: 3200 rpm
- Minimum starting torque: 4.9 Nm
- Stall torque: 7.2 Nm
- Torque at max power: 3.6 Nm
- Max output power: 0.6 kW
- Back Head Coaxial: No
- Front nut threaded: No
- Main Material type: Steel
- Motor Lubrication free: No
- Rotation drive: Reversible
- Shaft loading code: e
- Spindle type: Keyed shaft
- Starting system: None
- Output Spindle size: 10 mm
- Weight: 1.2 kg
-
New Grade - 24 Months Warranty from purchase is available on this product.
