Chicago Pneumatic MR84-15800-K-ATEX, ATEX Reversible Air Motor
- Product Description
- Technical Specification
- Warranty Details
-
Product Number: 2051479244
Delivering reliable, explosion-safe rotary power in demanding industrial environments, the Chicago Pneumatic MR84-15800-K-ATEX reversible vane air motor is purpose-built for hazardous zone applications where electrical equipment simply cannot be used. Rated at 630 W and operating as a certified ATEX pneumatic motor, this unit gives engineers and maintenance teams the confidence to run continuous-duty processes without compromising site safety standards. At the heart of its performance is a vane-type design that draws 14 l/s air consumption at load, with air flow at max power also rated at 14 l/s, ensuring consistent torque delivery across the operating range. The 3/8-inch BSP air inlet thread integrates cleanly with standard industrial pneumatic supply lines, simplifying installation and reducing commissioning time. As a reversible air motor, it supports bi-directional rotation, making it genuinely versatile across assembly, mixing, conveying, and actuation tasks. The MR84-15800-K-ATEX sits within Chicago Pneumatic's trusted range of industrial air tools, sharing the robust engineering philosophy found across their pneumatic die grinder and air-powered die grinder product lines. Its compact vane motor architecture means it can be integrated into OEM machinery or custom fixtures with minimal space constraints. Whether driving a conveyor system in a petrochemical facility, powering agitation equipment in a paint or solvent plant, or running ancillary automation in a classified zone, this air motor delivers dependable, spark-free performance where it matters most.Product Feature: Low friction and lubrication-free design of vanes for ruggedness. Sustain stall torque loading indefinitely. Short and compact planetary gear system for versatile solutions Long lasting efficiency with low air consumption design Strong starting torque for mobility during operation About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.
-
- Air consumption at load: 14 l/s
- Air flow max power: 14 l/s
- Air inlet thread size (in): 3/8
- Air inlet thread type: BSP
- Max dynamic air working pressure: 6.3 bar
- Safety: Index of protection (IP code)
- Max free speed range: 15800 rpm
- Minimum starting torque: 0.96 Nm
- Stall torque: 1.42 Nm
- Torque at max power: 0.71 Nm
- Max output power: 0.6 kW
- Back Head Coaxial: No
- Front nut threaded: No
- Main Material type: Steel
- Motor Lubrication free: No
- Rotation drive: Reversible
- Shaft loading code: e
- Spindle type: Keyed shaft
- Starting system: None
- Output Spindle size: 10 mm
- Weight: 1.2 kg
-
New Grade - 24 Months Warranty from purchase is available on this product.
