Chicago Pneumatic MR84-1100-K-ATEX, ATEX Reversible Air Motor
- Product Description
- Technical Specification
- Warranty Details
-
Product Number: 2051479284
Engineered for demanding industrial environments where safety is non-negotiable, the Chicago Pneumatic MR84-1100-K-ATEX reversible vane air motor delivers a robust 630 W of continuous power output, making it a reliable choice for operations in potentially explosive atmospheres. Certified to ATEX standards, this pneumatic motor is purpose-built for hazardous locations across oil and gas, chemical processing, and mining industries where conventional electric motors simply cannot be deployed safely. Featuring a 3/8-inch BSP air inlet thread, the MR84-1100-K-ATEX integrates seamlessly into existing pneumatic systems and operates at an air consumption rate of 14 l/s at load, matching its maximum air flow at full power for predictable, consistent performance. The reversible vane design offers versatile directional control, giving operators the flexibility to tackle a wide range of torque-driven tasks without tool changes or downtime. As a high-quality air motor, it embodies the precision engineering and durability that Chicago Pneumatic has long been trusted to deliver across global industries. Compared to standard pneumatic motor alternatives, the ATEX-rated construction adds a critical layer of compliance and protection without compromising on output or efficiency. This unit is ideally suited for powering conveyor systems, agitators, hoists, and other machinery in classified hazardous zones where maintaining operational continuity and worker safety are equally essential priorities for facility managers and maintenance engineers.Product Feature: Low friction and lubrication-free design of vanes for ruggedness. Sustain stall torque loading indefinitely. Short and compact planetary gear system for versatile solutions Long lasting efficiency with low air consumption design Strong starting torque for mobility during operation About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.
-
- Air consumption at load: 14 l/s
- Air flow max power: 14 l/s
- Air inlet thread size (in): 3/8
- Air inlet thread type: BSP
- Max dynamic air working pressure: 6.3 bar
- Safety: Index of protection (IP code)
- Max free speed range: 1100 rpm
- Minimum starting torque: 13.5 Nm
- Stall torque: 20 Nm
- Torque at max power: 10.1 Nm
- Max output power: 0.6 kW
- Back Head Coaxial: No
- Front nut threaded: No
- Main Material type: Steel
- Motor Lubrication free: No
- Rotation drive: Reversible
- Shaft loading code: e
- Spindle type: Keyed shaft
- Starting system: None
- Output Spindle size: 10 mm
- Weight: 1.3 kg
-
New Grade - 24 Months Warranty from purchase is available on this product.
