Chicago Pneumatic MR39-1700-KL-ATEX, ATEX Reversible Air Motor
- Product Description
- Technical Specification
- Warranty Details
-
Product Number: 2051478744
Delivering reliable, explosion-proof performance in the most demanding industrial environments, the Chicago Pneumatic MR39-1700-KL-ATEX reversible vane air motor brings 250 W of consistent power to applications where electrical equipment simply cannot operate safely. Engineered to ATEX certification standards, this pneumatic motor is purpose-built for hazardous locations including petrochemical facilities, refineries, and other classified zones where flammable atmospheres present a constant operational challenge. The MR39-1700-KL-ATEX operates with an air consumption of 7.9 l/s at load, matched precisely to its maximum power air flow, ensuring efficient energy transfer throughout the working cycle. A 1/4-inch BSP air inlet thread provides straightforward integration into standard pneumatic supply lines, making installation and maintenance refreshingly uncomplicated for maintenance teams working under pressure. As a reversible motor, it offers operators versatile directional control, expanding the range of tasks it can handle without additional tooling or setup time. With a compact and robust construction typical of Chicago Pneumatic air tools, this unit delivers the dependability professionals expect from a trusted global brand. The vane motor design ensures smooth, consistent torque output, making it equally well-suited as a drive unit within custom-built machinery, automated production lines, or specialist pneumatic die grinder assemblies where a certified air motor must perform without compromise. It is the definitive choice for plant engineers specifying ATEX-compliant pneumatic motor solutions in high-risk industrial settings.Product Feature: Low friction and lubrication-free design of vanes for ruggedness. Sustain stall torque loading indefinitely. Short and compact planetary gear system for versatile solutions Long lasting efficiency with low air consumption design Strong starting torque for mobility during operation About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.
-
- Air consumption at load: 7.9 l/s
- Air flow max power: 7.9 l/s
- Air inlet thread size (in): 1/4
- Air inlet thread type: BSP
- Max dynamic air working pressure: 6.3 bar
- Safety: Index of protection (IP code)
- Max free speed range: 1700 rpm
- Minimum starting torque: 3.7 Nm
- Stall torque: 5.4 Nm
- Torque at max power: 2.7 Nm
- Max output power: 0.3 kW
- Back Head Coaxial: No
- Front nut threaded: No
- Main Material type: Steel
- Motor Lubrication free: Yes
- Rotation drive: Reversible
- Shaft loading code: c
- Spindle type: Keyed shaft
- Starting system: None
- Output Spindle size: 12 mm
- Weight: 0.75 kg
-
New Grade - 24 Months Warranty from purchase is available on this product.
