Product Number: 2051478424
Delivering reliable rotational power in potentially explosive atmospheres, the Chicago Pneumatic MR25-290-KL-ATEX reversible vane air motor offers 160 W of output with a free speed of 290 RPM, making it an exceptional choice for controlled, low-speed industrial applications where safety and precision are non-negotiable. Designed to meet ATEX certification requirements, this pneumatic motor is engineered for use in hazardous environments where conventional electric motors pose an unacceptable risk, giving operators the confidence to work in classified zones without compromise. The motor connects via a compact 1/8-inch BSP air inlet thread, keeping installation straightforward while maintaining compatibility with standard pneumatic tooling setups. At load, air consumption sits at 5 l/s, matching the air flow required at maximum power and allowing facilities to plan their compressed air supply with accuracy. The reversible functionality adds genuine operational flexibility, enabling both clockwise and anti-clockwise rotation to suit a wide range of drive and torque applications. As a core component of air motor and air tools systems, this unit integrates seamlessly into automated machinery, conveyor drives, agitators, and specialist process equipment. Its vane motor construction ensures smooth, consistent torque delivery even under sustained load conditions. The Chicago Pneumatic MR25-290-KL-ATEX is the trusted solution for engineers specifying pneumatic motor technology in petrochemical, pharmaceutical, and other safety-critical industries where ATEX compliance is mandatory.Product Feature: Low friction and lubrication-free design of vanes for ruggedness. Sustain stall torque loading indefinitely. Short and compact planetary gear system for versatile solutions Long lasting efficiency with low air consumption design Strong starting torque for mobility during operation About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.
-
- Air consumption at load: 5 l/s
- Air flow max power: 5 l/s
- Air inlet thread size (in): 1/8
- Air inlet thread type: BSP
- Max dynamic air working pressure: 6.3 bar
- Safety: Index of protection (IP code)
- Max free speed range: 290 rpm
- Minimum starting torque: 14 Nm
- Stall torque: 21 Nm
- Torque at max power: 10.5 Nm
- Max output power: 0.2 kW
- Back Head Coaxial: No
- Front nut threaded: No
- Main Material type: Steel
- Motor Lubrication free: Yes
- Rotation drive: Reversible
- Shaft loading code: b
- Spindle type: Keyed shaft
- Starting system: None
- Output Spindle size: 10 mm
- Weight: 0.75 kg
-
New Grade - 24 Months Warranty from purchase is available on this product.
