Chicago Pneumatic M2501-5500-KSL, Non-Reversible Stainless Steel Air Motor
- Product Description
- Technical Specification
- Warranty Details
-
Product Number: 2051481334
Delivering reliable rotary power in environments where hygiene and corrosion resistance are non-negotiable, the Chicago Pneumatic M2501-5500-KSL non-reversible stainless steel air motor offers engineers and maintenance professionals a robust solution built to endure demanding industrial conditions. Constructed from high-grade stainless steel throughout, this pneumatic motor resists moisture, chemicals, and washdown procedures, making it an ideal choice for food processing, pharmaceutical manufacturing, and marine applications where standard materials would quickly degrade. At its core, this compact air motor delivers a maximum free speed of 5500 rpm with a maximum output power of 0.3 kW, providing consistent rotational performance across a wide range of light to medium-duty tasks. The minimum starting torque of 2.3 Nm ensures prompt engagement under load, while a stall torque of 2.4 Nm reflects a well-balanced torque curve suited to controlled, precision-driven applications. As a non-reversible design, it prioritises simplicity and reliability, reducing internal complexity and minimising maintenance requirements over extended service intervals. The M2501-5500-KSL integrates seamlessly into custom-built pneumatic systems, automated machinery, and specialised air tools where a dedicated drive source is required. Its stainless steel construction paired with dependable pneumatic motor performance makes it particularly well-suited to hygienic processing lines, laboratory automation equipment, and any application demanding clean-room compatible, corrosion-resistant rotary motion from a compact, efficient air-powered drive unit.Product Feature: Designed with limited retention areas on the housing and double viton nose seals to prevent contamination risk Low friction and lubrication-free design of vanes for ruggedness. Sustain stall torque loading indefinitely. Short and compact planetary gear system for versatile solutions Long lasting efficiency with low air consumption design Strong starting torque for mobility during operation About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.
-
- Max free speed range: 5500 rpm
- Max output power: 0.3 kW
- Minimum starting torque: 2.3 Nm
- Stall torque: 2.4 Nm
- Torque at max power: 1.2 Nm
- Air consumption at load: 5.3 l/s
- Air flow max power: 5.3 l/s
- Air inlet thread size (in): 1/8
- Air inlet thread type: BSP
- Max dynamic air working pressure: 6.3 bar
- Back Head Coaxial: No
- Front nut threaded: Yes
- Main Material type: Stainless steel
- Motor Lubrication free: Yes
- Rotation drive: Clockwise
- Shaft loading code: b
- Spindle type: Keyed shaft
- Starting system: None
- Output Spindle size: 10 mm
- Weight: 0.71 kg
-
New Grade - 24 Months Warranty from purchase is available on this product.
