Chicago Pneumatic CP3109-13AC, 1/4"(6mm) Angle Air Die Grinder
- Product Description
- Technical Specification
- Warranty Details
-
Product Number: 6151604060
The Chicago Pneumatic CP3109-13AC is a precision-engineered 1/4-inch angle die grinder built for professionals who demand consistent performance in tight, hard-to-reach workspaces. Delivering a robust 600 W of maximum power at a free speed of 13,000 RPM, this Chicago Pneumatic die grinder tackles metal grinding, deburring, surface finishing, and weld preparation with exceptional efficiency. Its compact 216 mm body length and lightweight 1.1 kg construction reduce operator fatigue during extended use, making it one of the more ergonomically considered air die grinders in its class. Engineered for reliability on the production floor and in the workshop, this pneumatic die grinder runs at an air consumption rate of 10 l/s at free speed, ensuring it performs consistently when connected to a standard industrial air supply. The 6 mm collet accommodates a wide range of rotary accessories, giving technicians the flexibility to switch between abrasive tools without downtime. Its angled head design provides enhanced access to confined areas where straight tools simply cannot reach, setting it apart from a conventional pencil die grinder configuration. The CP3109-13AC is ideally suited for automotive bodywork, aerospace fabrication, metal fabrication workshops, and general maintenance environments where a dependable cp die grinder is required to deliver precise material removal and smooth surface preparation day after day.Product Feature: Highest durability in demanding applications, up to 2,000 hours maintenance intervals Streamlined safety lever for operator safety Steel housing with an insulating composite over-housing for operator comfort and superior ergonomics Powerful 0.8hp (600 W) governed motor About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe.
-
- Length (L): 216 mm
- Weight: 1.1 kg
- Max power: 600 W
- Free Speed: 13000 rpm
- Air consumption at free speed: 10 l/s
- Air consumption at load: 15 l/s
- Air inlet thread size (in): 3/8
- Air inlet thread type: BSP
- Max dynamic air working pressure: 6.3 bar
- Min hose diam (16 ft hose length): 0.38 in
- Min hose diam (5 m hose length): 10 mm
- Sound Power: 96 dB(A)
- Sound Pressure: 85 dB(A)
- Uncertainty vibration-K: 1.4 m/s²
- Vibration: 3.7 m/s²
- Angle Type: Straight
- Collet max capacity: 1/4 (6.35mm)
- Collet/Collet holder/Collet nut type: Erickson series 300 type
- Exhaust: Rear
- Governor type: Ball
- Main Material type: Aluminium, Composite over-sleeve
- Rotative inlet: No
- Spindle lock: No
- Starting system: Safety lever
-
New Grade - 24 Months Warranty from purchase is available on this product.
