Lucas LTZ10S Shido Lithium Motorcycle Battery LiFePO4 - 12v 4Ah, 1 Year Warranty

Original price £40.32 - Original price £40.32
Original price
£40.32
£40.32 - £40.32
Current price £40.32
  • Product Description
  • Technical Specification
  • Warranty Details
  • Product Number: LTZ10S

    Motorcycle applications demand a battery that delivers reliable cold-start performance and consistent power output across varied riding conditions. The Lucas LTZ10S is a LiFePO4 lithium iron phosphate battery engineered for motorcycles, off-road vehicles and jetski use, offering a compact, lightweight solution where dependable cranking power is essential. Developed under the Lucas Motorsport range, this battery combines cutting-edge lithium technology with robust design and precision engineering. LiFePO4 chemistry delivers stable voltage output, a lower self-discharge rate than conventional lead-acid units and an extended cycle life, making it well-suited to seasonal or intermittent use. The technology supports start-stop functionality - verify compatibility with the product label prior to fitment. The LTZ10S operates at 12V with a rated capacity of 4Ah (C20) and a cold cranking amp rating of 150A (EN). Physical dimensions are 150mm x- 86mm - 94mm (L x- W x- H), with a weight of 2.75kg. The battery features a Type 2 terminal arrangement, polarity code 1 and hold-down code B00. It is a direct cross-reference for the YTZ10S. IP, MCA, Watt-Hour and NCC classifications are not applicable to this unit. The LTZ10S is available as part of the Lucas Motorsport lithium range alongside the LTZ7S and LTZ14S, providing options across differing capacity and fitment requirements." This battery is supplied with a 1-year manufacturer warranty. " . The range of Lucas Motorsport batteries brings together a winning combination of cutting edge technology, robust design and precision engineering for motorcycle, off-road and jetski applications. The built-in qualities of exceptional starting power - up to 30% more than traditional batteries - and the high resilience to deep, repeated discharge make this range of batteries the power source of choice. Key Feature: Backed by 1-year warranty for reliable use and dependable performance. Product Group: 2250, LUCAS MOTORCYCLE BATTERY, purpose-built for dependable performance in the intended application. Engineered as a AGM Battery, delivering consistent, reliable operation in daily use. Manufactured by Lucas, a trusted name in automotive batteries, known for dependable quality. Weighs 2.8 kg (6.1 lb) balancing power and manageability for easier installation and handling. OEM-style fitment supports straightforward replacement and proper mounting. 12V system compatible with standard vehicle electrical requirements. Compatibility: Tailored for motorcycles/2-wheelers with a compact footprint and stable voltage for dependable starts and lighting. Uses: Restores dependable starting for vehicles that need consistent, everyday performance. Suited to AGM Battery applications, delivering steady operation in daily driving conditions. Supports stable power delivery for ignition, lighting, and onboard electronics. Performs reliably across short trips and longer runs where dependable restarts are essential. About MachineRefurb: MachineRefurb is an e-commerce platform specialising in replacement parts, spares and consumables for construction, agriculture and industrial machinery, serving customers across Ireland, the United Kingdom and Europe. We offer an extensive catalogue of over 200,000 products to keep your machines running. Standard delivery: 1-7 working days across Ireland, the UK and Europe. Fitment Warning: You must check your current battery against the specifications of this battery before ordering to ensure that this is the correct battery for your vehicle. Check battery technology, dimensions, terminal type, polarity, capacity (AH) and cranking performance (CCA). We cannot guarantee correct fitment under any circumstances.

    • Brand: Lucas Automotive
    • Voltage: 12V
    • Capacity AH (C20): 4Ah
    • Cold Cranking Amps (EN): 150A
    • L x- W x- H: 150mm x- 86mm x- 94mm
    • Warranty period: 1 Year
    • Weight (Kg): 2.75
    • Capacity AH (C5):
    • Capacity AH (C10):
    • Capacity AH (C100):
    • Marine Cranking Amps (MCA):
    • Watt-Hours (WH):
    • Length (mm): 150
    • Width (mm): 86
    • Height Inc. Terminal (mm): 94
    • Terminal Placement: 1
    • Terminal Type: 2
    • Hold Down: B00
    • Case Size:
    • ETN Number:
    • TTNR:
  • New Grade - 24 Months Warranty from purchase is available on this product.
Frequently Asked Questions

Q1- What is the voltage and capacity of the Lucas LTZ10S?
ANS- The Lucas LTZ10S is a 12V lithium iron phosphate (LiFePO4) battery with a rated capacity of 4Ah (C20) and a cold cranking amp (CCA) rating of 150A to EN standard.

Q2- What are the dimensions and weight of the LTZ10S?
ANS- The LTZ10S measures 150mm in length, 86mm in width and 94mm in height including terminals. It weighs 2.75kg.

Q3- Is the Lucas LTZ10S a direct replacement for the YTZ10S?
ANS- Yes. The LTZ10S is a recognised cross-reference for the YTZ10S. Always confirm terminal layout, polarity and physical fitment against your application before installation.

Q4- What is the terminal arrangement and polarity of the LTZ10S?
ANS- The LTZ10S uses a Type 2 terminal arrangement with polarity code 1. Confirm terminal positions against your vehicle's battery compartment layout prior to fitment.

Q5- Does the LTZ10S support start-stop systems?
ANS- The LiFePO4 technology used in the LTZ10S supports start-stop functionality. However, compatibility must be verified against the product label and your specific vehicle requirements before fitment.

Q6- What battery chemistry does the Lucas LTZ10S use?
ANS- The LTZ10S uses lithium iron phosphate (LiFePO4) chemistry, which offers stable voltage output, low self-discharge and extended cycle life compared with conventional lead-acid batteries.

Q7- What hold-down type does the LTZ10S require?
ANS- The LTZ10S uses hold-down code B00. Refer to your vehicle's battery tray specification to confirm compatibility before ordering.

Q8- Are there other sizes available in the Lucas Motorsport lithium range?
ANS- Yes. The Lucas Motorsport lithium range includes the LTZ7S and LTZ14S, providing alternative capacity and fitment options for different motorcycle and off-road applications.

Q9- What warranty is provided with the Lucas LTZ10S?
ANS- The LTZ10S is supplied with a 1-year manufacturer warranty covering defects in materials and workmanship under normal operating conditions.

Q10- What are the delivery and returns terms for the LTZ10S?
ANS- Standard delivery is 1-7 working days. A 14-day returns policy applies For full terms, refer to the MachineRefurb delivery and returns policy at the time of order.

Q11- What are the delivery times?
ANS- Estimated delivery times are as follows:
* Ireland: 1-3 business days
* UK Mainland: 1-3 business days
* Northern Ireland: 3-7 business days
* European Union: 3-7 business days
All orders are shipped with tracking. You will receive tracking details by email once dispatched.

Q12- What is the warranty period for this product?
ANS- This product is covered under a 1-year warranty from the date of purchase.
